Trail 6
$825.00

COLOR
SIZE  Size Chart
This product is available for store pickup only. Learn more.
Article #

The Cannondale Trail 6 is a mountain bike built to raise your game and ignite a passion for the trail. Designed for the mountains and ready for anything.

  • Where it thrives: Low-impact trails, gravel roads, leisurely ride
  • What it's built for: Handling, durability
  • Light and durable SmartForm C3 Alloy frame
  • SR Suntour XCT suspension fork, 100mm travel
  • Shimano 8-speed shifting w/double chainring crank / Shimano hydraulic disc brakes
Drivetrain
Shimano 2 x 8
Fork
SR Suntour XCT
Frame
Aluminum
Tire Size
29 x 2.25" (27.5 x 2.25" - XS and S)
COMPONENTPART
Bottom BracketSealed bearing cartridge, square taper
ChainKMC X8, 8-speed
CrankProwheel, 36/22
Front DerailleurShimano Altus, 34.9 clamp
Rear CogsSunrace, 11-34, 8-speed
Rear DerailleurShimano Acera
ShiftersShimano M315 Rapidfire Plus, 8-speed
ForkSR Suntour XCT, 100mm, coil, 42mm offset (27.5") 46mm offset (29")
FrameSmartForm C3 Alloy, SAVE, 1-1/8" headtube, post mount disc, StraightShot internal cable routing, dropper post compatible, BSA-73
HeadsetSemi-Integrated, 1-1/8"
Front HubShimano HBTX 505
Front TireWTB Ranger Comp, 29x2.25" (27.5x2.25" - XS, SM), DNA Compound
Rear HubShimano FHTX505
Rear TireWTB Ranger Comp, 29x2.25" (27.5x2.25" - XS, SM), DNA Compound
RimsWTB SX19, 32h
SpokesStainless Steel, 14g
Tire Size2.25"
TiresWTB Ranger Comp, 29x2.25" (27.5x2.25" - XS, SM), DNA Compound
Wheel Size29"
Brake LeversTektro hydraulic disc
BrakesTektro M275 hydraulic disc, 160/160mm rotors
GripsCannondale Dual-Density
HandlebarCannondale Riser, 6061 Alloy, 25mm rise, 8° sweep, 6° rise, 720mm
SaddleCannondale Stage 3
SeatpostCannondale 3, 6061 Alloy, 31.6 x 350mm (XS - SM), 400mm (MD-XL)
Stem6061 Alloy, 31.8, 7°

* Specs subject to change

TrailXS (27.5")S (27.5")M (29")L (29")XL (29")
A Seat Tube Length (cm/ in)33/ 1338.1/ 1543.2/ 1747/ 18.553.3/ 21
B Top Tube Horizontal (cm/ in)53.5/ 21.157.7/ 22.760.9/ 2463.4/ 2565.9/ 25.9
C Top Tube Actual (cm/ in)N/AN/AN/AN/AN/A
D Head Tube Angle68º68°68°68°68°
E Seat Tube Angle73.5°73.5°73.5°73.5°73.5°
F Standover (cm/ in)67.3/ 26.571/ 2876.8/ 30.279.5/ 31.383.9/ 33
G Head Tube Length (cm/ in)9.5/ 3.79.5/ 3.710.5/ 4.111.5/ 4.512.5/ 4.9
H Wheelbase (cm/ in)105.4/ 41.5109.8/ 43.2114/ 44.9116.6/ 45.9119.2/ 46.9
I Front Center (cm/ in)62.1/ 24.466.5/ 26.270.2/ 27.672.8/ 28.775.4/ 29.7
J Chain Stay Length (cm/ in)44/ 17.344/ 17.344.5/ 17.544.5/ 17.544.5/ 17.5
K Bottom Bracket Drop (cm/ in)6/ 2.46/ 2.46.5/ 2.66.5/ 2.66.5/ 2.6
L Bottom Bracket Height (cm/ in)29.3/ 11.529.3/ 11.530.7/ 12.130.7/ 12.130.7/ 12.1
M Fork Rake (cm/ in)4.2/ 1.74.2/ 1.74.6/ 1.84.6/ 1.84.6/ 1.8
N Trail (cm/ in)9.7/ 3.89.7/ 3.810.1/ 410.1/ 410.1/ 4
O Stack (cm/ in)57.3/ 22.659.1/ 23.362.3/ 24.563.2/ 24.964.1/ 25.2
P Reach (cm/ in)36.5/ 14.440.2/ 15.842.5/ 16.744.7/ 17.646.9/ 18.5
Rider HeightBike Size
4'6" - 5'2"XS
5'1 - 5'4"S
5'4 - 5'8"M
5'7" - 6'0"L
6'0 - 6'3"XL
