Women's Quick CX 1
$1,400.00
+1
Women's Quick CX 1
$1,400.00
An urban-adventure bike for cities and town pathways, open countryside and everything else. Expand your horizons on one bike to do it all.
- Where it thrives: In town, Leisurely rides, On crowded streets
- What it's built for: Visibility, Agility, Comfort
- Light and durable SmartForm C3 Alloy frame / Suspension fork, 63mm travel, remote lockout
- SRAM SX Eagle 12-speed drivetrain / Shimano MT400 hydro disc brakes
- Vittoria 700x40c multi-surface tires / Integrated connectivity with Cannondale App
Drivetrain
SRAM SX Eagle, 1 x 12-speed
Fork
Suntour NEX-E25, 63mm
Frame
Aluminum
Tire Size
700 x 40c
| Component | Part |
|---|---|
| Frame | SmartForm C3 Alloy, SAVE, tapered head tube, Straightshot hidden cable routing, flat mount disc, rack/fender mounts, 360° reflectivity |
| Fork | Suntour NEX-E25, 63mm, tapered alloy steerer, coil, remote lockout, custom crown |
| Headset | Semi-Integrated, Tapered |
| Rear Derailleur | SX Eagle |
| Shifters | SRAM SX Eagle, 12-speed |
| Chain | SRAM SX Eagle, 12-speed |
| Crank | SRAM SX Eagle Power Spline, 38T |
| Rear Cogs | SRAM SX Eagle, 11-50, 12-speed |
| Bottom Bracket | Truvativ Power Spline |
| Brakes | (F) Tektro HD-T275 hydraulic disc, 160mm rotor / (R) Tektro HD-R280 hydraulic disc, 160mm rotor |
| Brake Levers | Tektro hydraulic disc |
| Rims | RD 3.0, double wall w/eyelet, 32h |
| Front Hub | Sealed Alloy Disc, QR |
| Rear Hub | Sealed Alloy Disc, QR |
| Spokes | Stainless Steel, 14g |
| Tires | Vittoria Terreno Dry, 700 x 40, reflective strip |
| Tire Size | 40 |
| Wheel Size | 700c |
| Front Tire | Vittoria Terreno Dry, 700 x 40, reflective strip |
| Rear Tire | Vittoria Terreno Dry, 700 x 40, reflective strip |
| Handlebar | Cannondale 3, 6061 Alloy Double-butted, 20mm rise, 9° back, 660mm |
| Stem | Cannondale 3 with Intellimount, Alloy, 31.8mm clamp |
| Grips | Fabric FunGuy |
| Saddle | Cannondale Fitness Ergo Double Density |
| Seatpost | Cannondale 3 6061 Alloy, 27.2 x 350mm |
| Wheel Sensor | Cannondale Wheel Sensor |
* Specs subject to change
| Quick CX | XS | S | M | L | XL | XXL |
|---|---|---|---|---|---|---|
| A Seat Tube Length (mm/ in) | 350/ 13.7 | 400/ 15.6 | 450/ 17.6 | 500/ 19.5 | 550/ 21.5 | 600/ 23.4 |
| B Top Tube Horizontal (mm/ in) | 566/ 22.1 | 582/ 22.7 | 597/ 23.3 | 612/ 23.9 | 628/ 24.5 | 643/ 25.1 |
| C Top Tube Actual (mm/ in) | 548/ 21.4 | 559/ 21.9 | 571/ 22.3 | 586/ 22.9 | 604/ 23.6 | 623/ 24.3 |
| D Head Tube Angle | 69° | 69° | 69° | 69° | 69° | 69º |
| E Seat Tube Angle | 73° | 73° | 73° | 73° | 73° | 73° |
| F Standover (mm/ in) | 677/ 26.5 | 725/ 28.3 | 764/ 29.8 | 802/ 31.3 | 840/ 32.8 | 876/ 34.2 |
| G Head Tube Length (mm/ in) | 90/ 3.6 | 108/ 4.3 | 126/ 5 | 143/ 5.6 | 162/ 6.4 | 180/ 7.1 |
| H Wheelbase (mm/ in) | 1091/ 42.6 | 1108/ 43.3 | 1124/ 43.9 | 1141/ 44.5 | 1158/ 45.2 | 1174/ 45.8 |
| I Front Center (mm/ in) | 648/ 25.3 | 666/ 26 | 682/ 26.6 | 732/ 28.6 | 698/ 27.3 | 715/ 27.9 |
| J Chain Stay Length (mm/ in) | 450/ 17.6 | 450/ 17.6 | 450/ 17.6 | 450/ 17.6 | 450/ 17.6 | 450/ 17.6 |
| K Bottom Bracket Drop (mm/ in) | 64/ 2.5 | 64/ 2.5 | 64/ 2.5 | 64/ 2.5 | 64/ 2.5 | 64/ 2.5 |
| L Bottom Bracket Height (mm/ in) | 293/ 11.5 | 293/ 11.5 | 293/ 11.5 | 293/ 11.5 | 293/ 11.5 | 293/ 11.5 |
| M Fork Rake (mm/ in) | 55/ 2.2 | 55/ 2.2 | 55/ 2.2 | 55/ 2.2 | 55/ 2.2 | 55/ 2.2 |
| N Trail (mm/ in) | 78/ 3.1 | 78/ 3.1 | 78/ 3.1 | 78/ 3.1 | 78/ 3.1 | 78/ 3.1 |
| O Stack (mm/ in) | 573/ 22.4 | 590/ 23.1 | 607/ 23.7 | 623/ 24.3 | 640/ 25 | 657/ 25.7 |
| P Reach (mm/ in) | 391/ 15.3 | 402/ 15.7 | 412/ 16.1 | 422/ 16.5 | 432/ 16.9 | 442/ 17.3 |
| RIDER HEIGHT | BIKE SIZE |
|---|---|
| 4'10" - 5'3" | XS |
| 5'2" - 5'7" | S |
| 5'5" - 5'10" | M |
